Color Force II 48™

Cyc, Wash & Effects LED Lighting which Changes the Game Again

The Chroma-Q® Color Force II 48™ is a truly multi-purpose LED fixture that is suitable for numerous entertainment lighting disciplines. With four powerful homogenized cells per foot/305mm, these units can be grouped and controlled to release your creativity. Unsightly color shadowing is eliminated with this innovative optical system that gives power enough to light nearly 12m of cyclorama. Perfect for a wide range of cyclorama, flood and wall washing applications where a powerful throw is needed. Available in 6 ft / 1.8m, 4 ft / 1.2m, 1 ft / 0.3m versions, these fixtures are specifically designed to fit in flight cases used with the original Color Force.



Details

Homogenised Output – Superior Colour Blend & No Unsightly Colour-Mixing Shadows Using the very latest fully homogenised optics found in the popular Chroma-Q® Color One 100™ product range, the Color Force II™ fixtures' output is a single, clean and pure beam of light, delivering a superior colour blend with no unsightly colour-mixing shadows.

The homogenised optics and improved Chroma-Q® technology provide even higher quality saturates and pastels, and a purer white - all from a single source.

Theatrical Grade Dimming

Theatrical grade dimming emulates the extremely smooth dimming curve of tungsten fixtures.

Colour Consistency

Factory calibration ensures all Color Force II™ units are colour matched, so side by side they will be outputting consistently the same colour unit to unit, regardless of the batch of LEDs used or when the unit was manufactured.

Even More Creative Control

The new models also provide more creative control, with twice as many light engines accommodated within the same fixture lengths – providing independently controllable cells every 3 inches.

At least 50% Brighter

In addition, advances in LED production methods, combined with Chroma-Q®'s proprietary technologies, enable the Color Force II™ solutions to deliver at least 50% more output compared to their predecessors – now capable of lighting up to a 12m cyc or surface.

RDM

Extensive RDM functionality is provided through wired, or the optional LumenRadio CRMX, connection.

Lighting Fixtures Johannesburg Products
Lighting Fixtures Durban



  • Featuring Chroma-Q's proven award winning technology
  • Over 13,500 hot lumens will easily wash a 12m / 39 ft. cyc
  • Extremely smooth, uniform output
  • Homogenized RGBA colour mixing
  • Pixel control to 76mm/3in increments
  • High CRI of 92
  • Theatrical grade dimming
  • Rugged extruded aluminium body
  • Built-in power supply
  • Chroma-Q calibration means: superior fixture-to-fixture consistency
  • Works great in any theatre, TV, concert touring, exhibitions or corporate event
  • Optional internal LumenRadio
  • Touchscreen user interface
  • Technical Specifications
    Product Code
    • Color Force II 48
    • CHCF248RGBA - Black
    • CHCF248RGBAW - White
    • CHCF248RGBALR - Black with LumenRadio
    • CHCF248RGBALRW - White with LumenRadio

    Net Dimensions
    • 1,181mm x 165mm x 191mm / 46.5" x 6.5" x 7.5"

    Net Weight
    • 18 Kg / 40 lb

    Shipping Dimensions
    • 1,295mm x 305 mm x 320mm / 51'' x 12'' x 12.5''

    Shipping Weight
    • 21 Kg / 46 lb

    Power Supply
    • Built-in

    Power Input Rating
    • 100-240V AC, 50-60 Hz, 550VA
    Power Factor
    • 0.97 @ 120V AC,
    • 0.92 @ 240V AC

    Power Consumption
    • 533W @ 120V AC,
    • 533W @ 240V AC

    Idle Power Consumption
    • 27W @ 120V AC,
    • 30W @ 240V AC

    Typical Power & Current
    • Measurements done with all LEDs at maximum intensity. Measurements made at nominal voltage. Allow for a deviation of +/- 10%.
    Power Connectors In/Out
    • Neutrik powerCON TRUE1

    Data Connectors In/Out
    • Neutrik XLR 5-pin

    Control Protocol
    • ANSI E1.11 USITT DMX 512-A
    Cooling System
    • Forced

    Operating Temperature
    • 0°C to 40°C

    Construction
    • Anodised aluminium extrusion

    Colour
    • Black

    Built-In Hardware
    • Quick release lever for tilt adjustment

    IP Rating
    • IP20

    Approvals
    • CISPR 22 :2006/EN55022 :2006 & CISPR 24 :1997/EN55024 :1998, ICES-003 :2004 & FCC Part 15 Subpart B: 2007, CSA C22. No. 166-M1983:R2008 UL 1573:2003; UL 8750
